BioMini Combo

BioMini Combo supports contact and contactless smartcards with
optional SAM slot. Combined with fingerprint sensor, the scanner
provides capability for two factor authentication for versatile security
solution applications.

Download Brochure

Description

Machine-learning based
Live Finger Detection(LFD)
Technology

BioMini Combo provides advanced machine-learning based Live
Finger Detection technology that distinguishes fake fingerprints
made from various materials including clay, rubber, silicon, glue,
paper, film and more.

Multi Dynamic
Range (MDR) Technology

BioMini Combo can acquire fingerprint regardless of external
light or fingerprint conditions, applying Suprema’s proprietary
MDR technology, an improvement on existing HDR technology.
It can get normal fingerprints even under 100,000 LUX direct light,
which is equivalent to direct sunlight.

FBI PIV and Mobile ID FAP20
Certified Image Quality

The Scanner features Large Platen that spans
0.71” x 1.0” (18mm x 25.4mm) wide, which is well
above the FAP20 Standard that spans 0.6” x 0.8”.

Additional information

Industries

Energy & Utilities, Healthcare, Manufacturing, Public Sector, Retail

Reviews

There are no reviews yet.


Be the first to review “BioMini Combo”

  • · PC/Network Security
    · Smartcard Application
    · Time and Attendance System
    · Public Application
    · Health and Medical
    · Telecommunication
    · Banking/Finance
    · POS/mPOS
    · ATM/Kiosk
    · Enterprise
Main Sensor Type Optical
Resolution / Gray Scale 500 ppi / 256 levels
Platen Size 18.0 x 25.4 mm
Sensing Area 16.2 x 24.3 mm
Image Size 320 x 480 pixels
Image Certificate FBI PIV and FBI Mobile ID FAP 20
Template Format Suprema, ISO 19794-2, ANSI 378
Image Format RAW, BMP, WSQ, ISO 19794-4
Live Fingerprint Detection Supported
IP Rating IP65(Sensor Surface)
Contact Card Support Contact Smart Card Reader ISO 7816 Class A/B/C (5V, 3.0V, 1.8V) T=0, T=1 EMV2000 contact smart card with SAM Slot(optional, max 2x SAM)
Contactless Card Support Contactless Smart Card Reader ISO/IEC 14443 A&B, Mifare, Felica NFC Forum tag types (Jewel, Mifare Ultralight, Felica, Felica lite, Mifare, DesFire)
EMV2000 Contactless Smart Card
Frequency 13.56MHz +/- 7KHz
Distance transaction: Up to 10cm
Baud: 106/212/424/848 kbit/s
Interface USB 2.0 High Speed
CCID, PC/SC driver
Hardware Operating Temperature -10 ~ 50°C
Operation Humidity 0 ~ 90% RH
Certification CE, FCC, KC, RoHS, WHQL
Dimensions(W x L x H) 95.7 x 114.8 x 52.6 mm
Weight 280g
Compatibility Operating System Windows XP, Vista, 7, 8, 8.1, 10 32/64bit
Ubuntu, Debian, Fedora, OpenSUSE, CentOS 32/64bit
